Modular Ice Machine, Half Cube, Water-Cooled, 460 Lbs., 30-Inch Width

IM-0460-WC

Maestro Modular Ice Maker, cube-style, 30″W, water-cooled, self-contained condenser, production capacity up to 463 lbs/24 hr at 70°/50° (407 lbs at 90°/70°), diagnostic control panel, auto cleaning cycle, ABS antimicrobial interior, 304 stainless steel exterior, full-size cubes, 115v/60/1-ph, NEMA 5-15P, CE, cETLus, ETL-Sanitation

Features

• Water-cooled, full cube, modular

• Up to 463 lbs production capacity (70F/50F, 24 Hours)

• 304 stainless-steel exterior (durable & rust-resistant)

• Simple diagnostic panel to assist service & maintenance

• Cleaning switch for auto cleaning cycle

• Magnetic frame cleanable condenser air filters

• Adjustable flush time to reduce scale & cleaning cost

• ABS antimicrobial interior to reduce slime & cleaning cost

• Water distributor tube & water sump removed w/o tools

• Heavy duty water curtain, pins & hangers for easy removal

• Hinged front doors for easy access

• No screws on side or back panels for easy access

• Sides & top vents for optimal ventilation

• Improved evaporator section to reduce airborne bacteria

• Power cord with NEMA 5-15 plug

• R-404A refrigerant

Specifications

  • Ice Type: Cube
  • Condenser Type: Water Cooled
  • Dimensions: 30" width x 22.60" height x 24.80" depth
  • Product Weight, Ship Weight: 162.30lbs, 192lbs
  • Electrical: 115V/60Hz/1-Phase

Filtration

Icetro America always recommends using a dedicated filtration system for its ice machines. However, using the IcePro filter with Citryne™ and registering at icetrowaterproducts.com/registration will add one (1) year of warranty coverage.

Warranty

Ice Maker: 3-Years Parts + Labor; Evaporator: 5-Year Parts + Labor; Compressor: 5-Year Parts, 3-Years Labor

Resources

Icetro IM 0460 IceMachine SpecSheet Download
Icetro IM Cuber FND User Guide Download
Icetro IM-0350-0460-0550-0750-1100-1700-2000 User Manual Download
2024 Ice Machine Catalog, 12 pp Download
Icetro 2024 Ice Machine Catalog (4 pp) Download
Icetro Ice Machines Features and Benefits Download
Icetro Ice and Slush Trifold Download
Icetro Tech Handbook Cubers Download
Icetro IM0460W Modular PartsList 1 Download
Revit-QF Icetro IM 0460 WC WH Download
Revit-Icetro IM 0350 AC AH VE Download
Revit-Icetro IM 0350 AC AH VP Download
Revit-Icetro IM 0350 AC AH VS Download

Parts
